MC68332GCFC16

MC68332GCFC16, 32-Bit Modular Microcontroller, 16MHz, 132-PQFP, 4.5 V to 5.5 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.93~6.61 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.93~6.61

PartNumber:: MC68332GCFC16

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: QFP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Rosy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-05

From Other Seller

Part Number:MC68332GCFC16
US $3.93 - 6.61
ALC662

US $0.80 - 1.50 / Piece
(0) Remove
LM2576T-5.0

US $0.20 - 0.40 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MC68332GCFC16, a highly-integrated 32-bit microcontroller, combines high-performance data manipulation capabilities with powerful peripheral subsystems. The MC68332GCFC16 is built up from standard modules that interface through a common intermodule bus (IMB). Standardization facilitates rapid development of devices tailored for specific applications. The MC68332GCFC16 incorporates a 32-bit CPU (CPU32), a system integration module (SIM), a time processor unit (TPU), a queued serial module (QSM), and a 2-Kbyte static RAM module with TPU emulation capability (TPURAM).

Parametrics

MC68332GCFC16 general specifications: (1)RAM Size:2K x 8; (2)Number of I/O:15; (3)Package/Case:132-BQFP Bumpered; (4) Speed:16MHz; (5)Oscillator Type: Internal; (6)Packaging: Tray; (7)Program Memory Type: ROMless; (8)Core Processor:CPU32; (9)Core Size:32-Bit; (10)Operating Temperature:-40℃ to 85℃; (11)Connectivity:EBI/EMI, SCI, SPI, UART/USART; (12)Peripherals: POR, PWM, WDT; (13)Voltage - Supply (Vcc/Vdd):4.5 V to 5.5 V; (14)Lead Free Status: Contains Lead; (15)RoHS Status: RoHS Non-Compliant.

Features

MC68332GCFC16 features: (1)32-Bit Architecture; (2)Virtual Memory Implementation; (3)Table Lookup and Interpolate Instruction; (4)Improved Exception Handling for Controller Applications; (5)High-Level Language Support; (6)Background Debugging Mode; (7)Fully Static Operation ; (8)External Bus Support; (9)Programmable Chip-Select Outputs; (10)System Protection Logic; (11)Watchdog Timer, Clock Monitor, and Bus Monitor; (12)Two 8-Bit Dual Function Input/Output Ports; (13)One 7-Bit Dual Function Output Port; (14)Phase-Locked Loop (PLL) Clock System; (15)Dedicated Microengine Operating Independently of CPU32; (16)16 Independent, Programmable Channels and Pins; (17)Any Channel can Perform any Time Function; (18)Two Timer Count Registers with Programmable Prescalers; (19)Selectable Channel Priority Levels.
