Product Summary

The IRF7303TRPBF is a HEXFET power MOSFET. The IRF7303TRPBF utilizes advanced processing techniques to achieve the lowest possible on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET are well known for, provides the designer with an extremely efficient device for use in a wide variety of applications.

Parametrics

IRF7303TRPBF absolute maximum ratings: (1)ID @ TA=25℃ 10 Sec. Pulsed Drain Current, VGS @10V: 5.3A; (2)ID @ TA=25℃ Continuous Drain Current, VGS @10V: 4.9A; (3)ID @ TA=70℃ Continuous Drain Current, VGS @10V: 3.9A; (4)IDM Pulsed Drain Current: 20A; (5)PD @ TA=25℃ Power Dissipation: 2.0W; (6)PD @ TA=25℃ Linear Derating Factor: 0.016W/℃; (7)VGS Gate-to-Source Voltage: ±20V; (8)dv/dt Peak Diode Recovery dv/dt: 5.0V/ns; (9)Junction and Storage Temperature Range: -55℃ to 150℃.

Features

IRF7303TRPBF features: (1)Generation V Technology; (2)Ultra Low On-resistance; (3)Dual N-channel Mosfet; (4)Surface Mount; (5)Available in Tape and Reel ; (6)Dynamic dv/dt Rating; (7)Fast Switching; (8)Lead-Free.

Diagrams

IRF7303TRPBF Pin Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRF7303TRPBF
IRF7303TRPBF

International Rectifier

MOSFET MOSFT DUAL NCh 30V 4.9A

Data Sheet

0-1: $0.72
1-25: $0.44
25-100: $0.30
100-250: $0.29
