Product Summary

The CM600DU-24NFH is a Mitsubishi IGBT module. The applications of the CM600DU-24NFH include AC drive inverters & Servo controls, etc.

Parametrics

CM600DU-24NFH absolute maximum ratings: (1) VCES Collector-emitter voltage: 1200V; (2) VGES Gate-emitter voltage: ±20V; (3) IC Collector current: 75A; (4) ICM Collector current: 150A; (5) IE Emitter current: 75A; (6) IEM Emitter current: 150A; (7) PC Maximum collector dissipation: 520W.

Features

CM600DU-24NFH features: (1) IC: 75A; (2) VCES: 1200V; (3) Insulated Type; (4)7-elements in a pack.

Diagrams

<IMG border=0 alt="CM600DU-24NFH block diagram" src="http://www.seekic.com/uploadfile/ic-mfg/2012102575654664.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CM600DU-24NFH
CM600DU-24NFH


IGBT MOD DUAL 1200V 600A NFH SER

Data Sheet

0-1: $218.22
