Product Summary

The TEESVA1C106M8R is a E/SV series Tantalum chip capacitor. NEC TOKIN’s tantulum capacitors offer the designer advanced technological design and excellent performance characteristics for filtering, bypassing, coupling, decoupling, blocking, and R C timing circuits. The TEESVA1C106M8R is used extensively in industrial, commercial, entertainment, and medical electronic equipment.

Parametrics

TEESVA1C106M8R absolute maximum ratings: (1)Operating temperature: -55 to +125℃; (2)Rated voltage: 2.5 V, 4V; (3) Derated voltage: 1.6V, 2.5V; (4) Surge voltage: 3.3VF, 5.2V; (5) Capacitance: 33μF to 47μF; (6) Capacitance tolerance: ±20%.

Features

TEESVA1C106M8R features: (1) Lead-free type. In conformity to ROHS; (2) Offer a range of small, high-capacity models; (3) Succeed to the latest technology plus outstanding performance.

Diagrams

TEESVA1C106M8R block diagram
