TLV5630I

8CH, 283KSPS, pin-compatible, eight-channel, 12bit voltage output DAC, SOP-20, 18mW, 1μs

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.05~15.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $7.05~15.10

PartNumber:: TLV5630I

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Rosy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-26

From Other Seller

Part Number:TLV5630I
US $7.05 - 15.10
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TLV5630I is a pin-compatible, eight-channel, 12bit voltage output DAC with a flexible serial interface. The serial interface allows glueless interface to TMS320 and SPI, QSPI, and microwire serial ports. The TLV5630I is programmed with a 16-bit serial string containing 4 control and 12 data bits. Additional features are a power-down mode, an LDAC input for simultaneous update of all eight DAC outputs, and a data output which can be used to cascade multiple devices, and an internal programmable band-gap reference. The applications of the TLV5630I include: (1) Digital Servo Control Loops; (2) Digital Offset and Gain Adjustment; (3) Industrial Process Control; (4) Machine and Motion Control Devices; (5) Mass Storage Devices.

Parametrics

TLV5630I absolute maximum ratings: (1)Supply voltage, (AVDD, DVDD to GND): 7 V; (2)Reference input voltage range: - 0.3 V to AVDD + 0.3; (3)Digital input voltage range: - 0.3 V to DVDD + 0.3; (4)Operating free-air temperature range, TA: -40℃ to 85℃; (5)Storage temperature range, Tstg: -65℃ to 150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

TLV5630I features: ((1)Eight Voltage Output DACs in One Package: 12-Bit; 1μs in Fast Mode; 3μs in Slow Mode; (2)Programmable Settling Time vs Power Consumption: 1μs in Fast Mode; 3μs in Slow Mode; 18mW in Slow Mode at 3 V; 48mW in Fast Mode at 3V; (3)Compatible With TMS320 and SPI Serial Ports; (4)Monotonic Over Temperature; (5)Low Power Consumption: 18mW in Slow Mode at 3 V; 48mW in Fast Mode at 3 V; (6)Power-Down Mode; (7)Internal Reference; (8)Data Output for Daisy-Chaining.
